Rotary Vacuum Evaporator
Digital Rotary Evaporator with Motorized & Manual Lifting
Rotary Evaporators are efficient laboratory distillation units for applications like standard solvent distillation & powder drying. Along with carefully designed accessories, it becomes a workhorse in any laboratory. We have a wide range of Rotary vacuum evaporators starting from 10 liters to 100 liters capacity. We supply a manual Rotary Evaporator & a Fully automatic rotary evaporator with temperature & timer-controlled PID.
Yatherm Scientific manufactures and supplies a standard and customized (in terms of functionality and capacities) exclusive line of Rotary Evaporators. Rotary vacuum Evaporator equipped with Motorized Lifting Glass parts, SS water bath & SS fixing Rods. Outer Construction MS powder Coated & ISI mark u shape SS heaters for uniform temperature in a Water bath.
We offer quality equipment with a year warranty and after-sales support for a long time. We offer the best prices in India for standard and customized equipment with 10 years of spare parts availability. Glass Parts are the integrated part of the machine which comes doesn’t come under warranty.
Rotary Evaporator Parts and Function
Vacuum degree
The degree of Vacuum is the most important parameter of the Rotary Vacuum Evaporator. It is somewhere related to the property of solvents such as H2O, CH3CooH, CHCL3 & C2H5OH are used in Chemical Industry. Normal vacuum Pumps are not compatible with an organic solvent, we should choose a water ring corrosion-free vacuum pump.
Electric Motor
Pure Copper AC motor in Mild Steel PCRC coated shell for rotating the Rotary Flask. Flask rotation will be shown in the RPM meter. The real image of the Electric Motor is shown below.
Water Bath
The water bath is designed with SS 304 inner chamber and SS 304 Water heater. Outer Body construction comes with GI powder coated and optional SS 304/SS 316 Construction. Chamber Capacity starts from one liter to Twenty liters connected with standard electrical fitting to the machine.
Water Bath Chiller
A water bath chiller is an optional accessory required with Rotary Evaporator for cooling down the condenser liquid. It provides chilled water which acts as a catalyst in the distillation process by cooling the vapors of chemicals. Water bath equipped with a cooling bath chamber capacity of 5 to 100 liters according to the requirement of customers. The temperature range of the Chiller starts from ambient to -10, -20, -30 & -40 degrees Celsius. The Water Bath chiller has a temperature-controlled facility with a water circulatory pump for uniform temperature.
Features
- Digital RPM Display
- Modular design
- High Borosilicate Glass with corrosion resistance
- Digital Temperature Display
- Offering various spare parts like a vacuum pump, water circulatory bath & vacuum control
- SS Water Bath
- Manual Lifting
- Motorized Lifting
- ISI mark U-type heater
Yatherm Models
- Manual Handle Model
- Motorized Model
ROTARY -2M EVAPORATOR:
Yatherm ROTARY – 2 M evaporator is designed for the removal of solvents from samples with the help of an evaporator. This equipment is specially manufactured for chemical laboratories. Round Flask continuously rotates and creates a vacuum condition by heating & condensation. This process removes the solvent which can be collected in any container for reuse if required.
Technical Specifications: –
| Model Number | ROTARY -2M |
| Listing Type | Manual |
| Condenser Type | Vertical/Horizontal |
| Rotation Speed (RPM) | 10-300 |
| Vapor Tube | Single piece with Sleeve for Easy Removal |
| Integrated Combi-Clip | Yes |
| Suitable flask size (ml) | 50-2000 ml |
| Rotation speed setting | Digital LED Display |
| Motor Power | 60 Watt |
| Heating Capacity | 1000 Watt |
| Total Power | 1060 Watt |
| Temperature Range | Room temperature +5°C  to 200°C |
| Temperature Accuracy | +/- 0.1 °C |
| Overheat Protection | Safety cutoff over +5 (oC) |
| Temperature Setting | PID-controlled LED Display With SV/PV |
| Secondary Protection Cutoff | Â Safety Thermostat |
| Water Bath Construction | SS 304 Â / SS 316 L |
| Volume Heating bath (L) | 4.5 L – Dia 255 mm Suitable 50- 2000 ml |
| Bath Position | It will be adjustable, and fixed according to the requirement |
| Sealing ring | Graphite PTFE |
| Power Supply | 220 V +/- 10% , 50 Hz/60 Hz |
Â
ROTARY – 2A EVAPORATOR:
Yatherm YS – 2A evaporator is a fully automatic rotary evaporator with motorized lifting. YS–2A is specially designed for a fully automatic purification & distillation process by just setting up temperature and RPM. Rotation of the flask gives a fine thin film in vacuum condition by condensation and heating. Yatherm Rotary’s price is economical in India with all advanced features.
Technical Specifications: –
| Model Number | ROTARY – 2A |
| Lift Type | Automatic Motorized |
| Condenser Type | Vertical/Horizontal |
| Rotation Speed (RPM) | 20-300 |
| Vapour Tube | Single piece & Sleeve |
| Integrated Combi-Clip | Yes |
| Suitable flask size (ml) | 50-2000 ml |
| Rotation speed setting | Digital LED Display |
| Rotation Driver | Electronic Speed Control |
| Motor Power | 60 Watt |
| Heating Capacity | 1000 Watt |
| Total Power | 1060 Watt |
| Temperature Range | Room temperature to  200 °C |
| Temperature Accuracy | +/- 0.1 °C |
| Overheat Protection | High  Low Alarm With Cut off system |
| Temperature Setting | DIGITAL with SV/PV setting |
| Temperature Control | PID controlled with Autotune facility |
| Secondary Protection Cutoff |  Safety Thermostat can be set 10-30 °C higher than the set value |
| Material Heating Bath | SS 304 / SS 316 L |
| Volume Heating bath (L) | 4.5 L – Dia 255 mm Suitable 50- 2000 ml |
| Bath Position | Adjustable |
| Sealing ring | PTFE |
| Power Supply | 220 V +/- 10% , 50 Hz/60 Hz |
